Gel-Sealed Weatherproof Flip Cover for 1/2" Jumper Cable to 4.3-10 Mini DIN Connector, Antenna or Rru Connection

HGS Series Gel Seal Weatherproofing Enclosure Kitsfor Coaxial Cables, Antenna or RRU RF InterfacesDescriptionHarshMet HGS series gel closure is a weatherproofing system for sealing coaxial cable jumper-to-feeder, jumper-to-antenna, jumper-to-RRU, and jumper-to-TMA connectors exposed to the outside environment. The

Featured Products

HGS Series Gel Seal Weatherproofing Enclosure Kits
for Coaxial Cables, Antenna or RRU RF Interfaces
Description
HarshMet HGS series gel closure is a weatherproofing system for sealing coaxial cable jumper-to-feeder, jumper-to-antenna, jumper-to-RRU, and jumper-to-TMA connectors exposed to the outside environment. The housing contains an innovative gel material and provides an efficient moisture block eff ectively water-proofing the connectors. HGS series closures are re-enterable, reusable and tool-less, making it time-saving, cost-effective and installer-friendly weatherproofing solution for the mobile base stations industry.The ease of installation and the long term protection makes it a reliable and cost eff ective sealing solution for outside plant cables and connectors

Benefits/Features

Sealing properties of the gel provide a reliable protection over a wide temperature range (-40°C/+ 70°C)
Wraparound and no disconnection of the connector
Quick and easy to install
Easy removable and re-usable
Gel material provides an effective barrier against ingress of water and other contaminant's - IP rating 68 Acc IEC/EN 60529
No tape, no mastics or tools required for installation and removal

Selection Table

Part NumberRF Coax Connections ProtectedConnector TypeDesign
HGS-12A1/2"& 1/2"Superflex Jumper to Antenna /RRU Connections7/16 DINLong Large Version
HGS-12AS1/2"& 1/2"Superflex Jumper to Antenna /RRU Connections7/16 DINShort Small Version
HGS-10431/2"& 1/2"Superflex Jumper to Antenna /RRU Connections4.3-10/4.1-9.5 Mini DinSlim Version
HGS-12TD-RRU1/2"Superflex Jumper to Antenna /RRU ConnectionsN TypeSlim Version
HGS-38TD-RRU3/8"Superflex Jumper to Antenna /RRU ConnectionsN typeSlim Version
HGS-78A7/8"& 7/8"Superflex Jumper to Antenna /RRU Connections7/16 DIN/
HGS-12781/2"& 1/2"Superflex Jumper to 7/8"& 7/8"Superflex Feeder Connections7/16 DIN or N Type/
HGS-121141/2"& 1/2"Superflex Jumper to 1-1/4"& 1-1/4"Superflex Feeder Connections7/16 DIN or N Type/
HGS-121581/2"& 1/2"Superflex Jumper to 1-5/8"& 1-5/8"Superflex Feeder Connections7/16 DIN or N Type/
HGS-78G7/8" & 7/8"Superflex Grounding Transitions//
HGS-12G1/2" & 1/2"Superflex Grounding Transitions//


Manufacturers Cross Reference

HarshMet P/N
(HarshSeal HGS)
Eupen
(Eucaseal)
TE(Tyco) P/N
(GSIC)
3M P/N
(OSCW, SLC)
HGS-12AES-12-BOXGSIC-1/2-ANT-L
(D80635-000)
OSCW Series-OSCW-J-1/2
Slim Lock Family- SLC-716
HGS-12ASES-12-BOXGSIC-1/2-ANT-S
(F58329-000)
HGS-1043//   Slim Lock Family-
SLC-A-MINI
HGS-1278ES-12-78GSIC-1/2-7/8
(D32473-000)

OSCW Series-OSCW-F-7/8

HGS-12114ES-12-114


GSIC-1/2-1 1/4
(C79091-000)
/
HGS-12158ES-12-158GSIC-1/2-1 5/8
(E97072-000)
/
HGS-12TD-RRU//Slim Lock Family-SLC-B-NANO
HGS-12G///
HGS-78G/FAST-GGND-0078/
HGS-38TD-RRU///
HGS-78A///
 //
