Model Number: ST-9801
ST-9801 is high performance UHF Long range RFID integrated reader,and the reading distance up to 10-20 meters. It supports fast tag read/write with high identification rate. The reader is widely used in RFID system such as logistics, vehicle access control, and anti-counterfeit and industrial production process control system.
Order List
| Model | Interface |
| ST-9801 | RS232, RS485, wiegand |
| ST-9801T | RS232, tcp/ip |
| ST-9801W | RS232, wifi |
| ST-9801TW | RS232, wifi,tcp/ip |
- Protocol: ISO18000-6B, ISO18000-6C(EPC C1G2)
- Work Frequency :865~868MHz, 902~928MHz frequency band(EU&US standard or customization);
- FHSS or Fix Frequency transmission;
- RF output power 30dbm in Max (adjustable);
- Built-in 12dbi antenna with effect distance up to 10m~20m;
- Work mode: Auto-running, Interactive and trigger-activating
- Power supply: DC 9V
- Communication: RS232, RS485, Wiegand26,TCP/IP/Wifi;
- Size:445mmx445mmx55mm, Package size:60*50*12cm, Gross weight:5kg
- Free SDK and demo software is provided
Absolute Maximum Rating
| ITEM | SYMBOL | VALUE | UNIT |
| Power Supply | VCC | 16 | V |
| Operating Temp. | TOPR | -10~+55 | ºC |
| Storage Temp. | TSTR | -20~+75 | ºC |
Electrical and Mechanical Specification
Under TA=25ºC,VCC=+9V unless specified
| ITEM | SYMBOL | MIN | TYP | MAX | UNIT |
| Power Supply | VCC | 8 | 9 | 12 | V |
| Current Dissipation | IC | 350 | 650 | mA | |
| Frequency | FREQ | 902 | 928 | MHz |
Instruction
| Item | Comment |
| Red | +9V |
| Black | GND |
| Yellow | Wiegand DATA0 |
| Blue | Wiegand DATA1 |
| Purple | RS485 R+ |
| Orange | RS485 R- |
| Brown | GND |
| White | RS232 RXD |
| Green | RS232 TXD |
| Grey | Trigger input(TTL level) |
